Rotor Thresh Bars

(Kile Thresh bars covered by one or more of the following U.S. Patent numbers

8,087,982; 8,475,247; 8,529,325; 8,602,856; 9,807,939; 10,321,633,11,641,806  & Patents Pending

Straight/Separator Bars & Kicker Bars

Bars for AFX/Specialty Rotors, Standard Rotors & Case IH Small Tube Rotors

Improve rotor thresh with Kile bars for AFX/Specialty and small tube rotors. With the wider area, Kile rotor bars feed the crop to the concave to perform a more complete thresh. Threshing is the act of grain rubbing on grain.



K 505TD Bar

(10 Degree Extended Rasp)



K 505TD-extended rasp (for Specialty,  AFX & Flagship rotors)

The K505TD Bar is an all purpose bar, with extended rasped ramp and has a 10 degree side.







K 506-Extended rasp (for Specialty, AFX & Flagship rotors)





The K 506 is an all purpose bar with a 28 degree side. It's extended rasped ramp, with aggressive face area, creates more crop contact allowing more crop to rub on itself. These deeper and wider rasps, on each bar, are aggressive yet gentle on the crop allowing the material to be 'managed' thru the threshing/separating system.



                                                         OEM Bar                                                                 K506 Bar

K 506                                                                                                                                         K 505TD



K 506-Extended rasp                                 K505 Ten Degree bar

Features:

  • wider bar section for crop feeding
  • 26% larger surface area per bar than OEM
  • 40 degree rasped ramp angle
  • 1.4 times larger surface area on ramp than OEM
  • wider and deeper extended rasps are aggressive yet gentle on crops
  • significantly reduces over thresh
  • reduces cracks and splits in seed coats
  • enhances the separation of material for a cleaner tank sample
  • works well in all crops, especially corn, beans and small grains
  • available in cast chrome alloy (high impact resistant) or ductile iron for excellent wearability
Installation Instructions for both 60 and 80 series rotors
Large tube rotor 60 80 thresh bar insta[...]
Adobe Acrobat document [1.5 MB]





K 507 and K 507C Bars

K 507 (28 degree bar with spike with extended rasp)

Insert shows spike with carbide

K 507C(Carbide Spike with extended rasp)



K 505SP

The K 505SP is a spiked 10 degree bar



Features and benefits of the K505SP & K 507 bar:

  • High performance bars for Case IH Specialy, AFX & Flagship rotors
  • More surface area for better separation
  • Requires less horsepower
  • Uses less fuel
  • Excellent wear ability
  • Caste chrome (high impact resistant)
Installation Instructions for both 60 & 80 series rotors
Large tube rotor 60 80 thresh bar insta[...]
Adobe Acrobat document [1.5 MB]











Kile Straight Separator Bars

Kile Straight Separator Bars for AFX/Specialty style rotors. Made of Caste Chrome for exceptional wear. Part # K 4017







Installation K 4017
K4017.pdf
Adobe Acrobat document [173.9 KB]

<< New text box >>

K 1327

Helical Kicker Bar



Made of hardened caste steel











Small Tube Rotor Thresh Bars





Now featuring our dual bolt small tube bars

These are our 2 bolt mount for small tube rotors

this bar stays on the mount because it is attached with 2 bolts.



K520.2 bar

All purpose extended rasp 28 degree bar



K 518.2 Bar

K 518.2 Small Tube Extended Rasp Bar-10 degree bar

This thresh bar is all purpose, used from small seed & grain to corn and bean.

K 519.2 Bar

K 519.2 Dual bolt Small Tube Spike Extended Rasp Bar-10 degree

This thresh bar is available with (K519.2C) carbide tip or without (K519.2). The carbide tip dramatically extends spike wear.



 K521.2 Bar

K 521.2 dual bolt 28 degree small tube spike extended rasp bar.













Available as the K 521.2 or K 521.2C Carbide Spiked with Small Tube Bar

This carbide spiked thresh bar is used if longer wear of the spike is needed, such in rice harvesting.







Features and benefits of the Kile® Small tube bars:

  • High performance bars for Case IH small tube rotors
  • Dual bolt mounting
  • More surface area for better separation
  • Requires less horsepower
  • Uses less fuel
  • Excellent wear ability
  • Caste chrome (high impact resistant)
  • With or without carbide tip spike
  • Carbide maintains spike integrity



Rice Push Bars

 K RPB-Rice Push Bars for Small Tube Rotors

Features and Benefits:

  • Dislodges rice from straw wads
  • Carbide face
  • 4 required per 40 bar small rotor
Installation/Placement Rice Push Bars
RPB Small Tube Rotor.pdf
Adobe Acrobat document [331.9 KB]



Cast Chrome Replacement OEM Cylinder Bars

  • OEM style replacement bars for either specialty or standard rotors available

Standard rotor bar kits for 40/60/80 rotors

               Straight bar                                           Helical bar

  • sold by sets and per piece for standard rotors
  • K 4009 kit for 60 Series
  • K 4010 kit for 80 Series
  • high quality caste chrome (impact resistant) excellent wearability
  • same features as OEM bars
